16. Install and tighten the engine oil tank filler cap.
NOTE:
Be sure to wipe off spilled oil on any parts after the
engine and exhaust system have cooled down.
CAUTION:
ECB00300
●
In order to prevent clutch slippage (since the
engine oil also lubricates the clutch), do not
mix any chemical additives. Do not use oils
with a diesel specification of “CD” or oils of
a higher quality than specified. In addition,
do not use oils labeled “ENERGY CONSERV-
ING II” or higher.
●
Make sure that no foreign material enters the
crankcase.
17. Start the engine, and then let it idle for several
minutes while checking it for oil leakage. If oil
is leaking, immediately turn the engine off and
check for the cause.
18. Turn the engine off, and then check the oil lev-
el and correct it if necessary.
EBU23470
Coolant
The coolant level should be checked before each
ride. In addition, the coolant must be changed at
the intervals specified in the periodic maintenance
and lubrication chart.
EBU23482
To check the coolant level
1. Place the ATV on a level surface.
NOTE:
The coolant level must be checked on a cold en-
gine since the level varies with engine tempera-
ture.
2. Check the coolant level in the coolant reser-
voir.
NOTE:
The coolant should be between the minimum and
maximum level marks.
Recommended oil:
See page 10-1.
Oil quantity:
Without oil filter element replacement:
1.75 L (1.85 US qt) (1.54 Imp.qt)
With oil filter element replacement:
1.85 L (1.96 US qt) (1.63 Imp.qt)
