RM-TT Installation Manual
Audio specifications
The contents of this manual apply to the latest specifications as of the publishing date. To
obtain the latest manual, access the Yamaha website then download the manual file.
Frequency response 160 Hz – 16 kHz (−10 dB)
Sampling rate 48 kHz
Bit depth 24-bit
Latency 57 [ms] (including signal processing)
Audio input/output (Dante)
1in×2out
• In1 : AEC reference signal
• Out1 : output of beam mix
• Out2 : output of beam mix (simple processed)
Maximum input level of SPL
(0 dBFs)
106.8 dB SPL
Self noise 6.3 dBA SPL
SNR
(Ref. 94 dB SPL at 1 kHz)
87.7 dBA
Sensitivity −12.8 dBFS/Pa
Dynamic range 100.5 dBA
Signal processing
• Auto voice tracking
• Selectable polar pattern: Cardioid, Hypercardioid,
Supercardioid, Omnidirectional, Bidirectional, Toroid
• AEC, NR, Dereverberation, Auto Mixer, AGC, User PEQ,
Output gain
