Yamaha RY8 - Getting Started; Setup & Power-On

12
Do not attempt to use an AC adaptor other than the Yamaha PA-3 or PA-1B. The use of an
incompatible adaptor may cause irreparable damage to the RY8, and may even pose a serious
shock hazard! ALWAYS UNPLUG THE AC ADAPTOR FROM THE AC POWER OUTLET WHEN
THE RY8 IS NOT IN USE.
When the AC adaptor plug is inserted into the RY8’s [DC IN] jack, the batteries are automatically
disconnected.
5. SETUP & POWER-ON
The RY8 can be powered by either an optional AC adaptor or six
batteries. Follow the instructions below based on the power source you
intend to use.
USING A POWER ADAPTOR.
Plug the DC output cable from an optional Yamaha PA-3 or PA-1B AC Adaptor
(available from your Yamaha dealer) snugly into the [DC IN] jack on the rear
panel, then plug the adaptor into a convenient wall AC power outlet.
GETTINGSTARTED.QX99.11.175:38PMページ12
GETTING STARTED
WARNING
