3-4-03: SENSITIVITY
VOICE EDIT MODE / 3: Full Edit. 3-4: PEG
3-4-03: SENSITIVITY
These parameters determined the overall range of the pitch EG, and how it is
affected by variations in keyboard velocity.
VCEPEGSens<Range>
1/8oc
t
+20
Range (Maximum PEG range)
Range: 1/8oct, 1/2oct, 1oct, 2oct
Sets the maximum range of pitch envelope generator pitch variation.
This parameter determines the total maximum range of the pitch envelope
generator, so a setting of “2oct” means that the maximum range is ±1 octave.
That is, if a level parameter is set to +63, for example, the pitch at that point
will be one octave above normal pitch.
Vel (Pitch EG velocity sensitivity)
Range: -7 … +7
Determines how the overall envelope depth of the pitch envelope generator
is controlled by velocity information.
Plus (“+”) values produce a deeper pitch envelope in response to higher
velocity, while minus (“–”) values produce a shallower pitch envelope in re-
sponse to higher velocity values. The greater the value the greater the change
in pitch envelope depth.
RateVel (Pitch EG rate velocity sensitivity)
Range: -7 … +7
Determines how the overall envelope length of the pitch envelope generator
is controlled by velocity information.
Plus (“+”) values produce a longer pitch envelope in response to higher
velocity, while minus (“–”) values produce a shorter pitch envelope in response
to higher velocity values. The greater the value the greater the change in pitch
envelope length.
Range
Vel
RateVel
[PLAY MODE] -> VCE PLAY -> [EDIT/COMPARE] -> 3: Full Edit -> [ENTER] -> 3-4: PEG -> [ENTER]
-> [PAGE] -> 3-4-03: Sensitivity -> [ENTER]
