Yamaha TRS-MS02 - System Exclusive Messages (XG); XG Parameter Changes; XG Bulk Dump and Request Messages; Hard Disk Recorder Control Messages

143
Tyros3
System Exclusive Messages (XG)
[MIDI]
System Exclusive Messages (Hard Disk Recorder Control)
[MIDI]
MIDI Event Data Format Voice
MIDI Reception MIDI Transmission
Regular/
Drum/
Organ Voice
Mic/Vocal
Harmony
Song Right1
Right2
Right3
Left
Keyboard Style Extra Right1
Right2
Right3
Left
M.Pad Style Song Upper
Lower
XG
Parameter
Changes
F0 43 1n 4C hh mm ll dd ... F7 * Refer to XG
Parameter Change
Table.
O
* Refer to XG Parameter Change Table.
O
* Refer to XG Parameter Change
Table.
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0001nnnn 1n = Device Number n=always 0(when transmit), n=0-F(when recieve)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm= Address Mid
0lllllll ll = Address Low
0ddddddd dd = Data
::
11110111 F7 = End of Exclusive
XG Bulk
Dump
F0 43 0n 4C aa bb hh mm ll dd ... dd cc F7
* Refer to XG
Parameter Change
Table.
O
* Refer to XG Parameter Change Table.
O
* Refer to XG Parameter Change
Table.
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0000nnnn 0n = Device Number n=always 0(when transmit), n=0-F(when recieve)
01001100 4C = Model ID
0aaaaaaa aa = Byte Count MSB
0bbbbbbb bb = Byte Count LSB
0hhhhhhh hh = Address High
0mmmmmmm mm= Address Mid
0lllllll ll = Address Low
0ddddddd dd = Data
::
0ddddddd dd = Data
0ccccccc cc = Checksum
11110111 F7 = End of Exclusive
XG
Prameter
Request
F0 43 3n 4C hh mm ll F7 - -O
* Refer to XG Parameter Change Table.
O
* Refer to XG Parameter Change
Table.
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0011nnnn 3n = Device Number n=always 0(when transmit), n=0-F(when recieve)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm= Address Mid
0lllllll ll = Address Low
11110111 F7 = End of Exclusive
XG Dump
Request
F0 43 2n 4C hh mm ll F7 - -O
* Refer to XG Parameter Change Table.
O
* Refer to XG Parameter Change
Table.
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0010nnnn 2n = Device Number n=always 0(when transmit), n=0-F(when recieve)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm= Address Mid
0lllllll ll = Address Low
11110111 F7 = End of Exclusive
MIDI Event Data Format Voice
MIDI Reception MIDI Transmission
Regular/
Drum/
Organ Voice
Mic/Vocal
Harmony
Song Right1
Right2
Right3
Left
Keyboard Style Extra Right1
Right2
Right3
Left
M.Pad Style Song Upper
Lower
Hard Disk
Recorder
Control
F0 43 73 01 50 19 00 00 dd F7 X X
O
X XXOX
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01110011 73 = Tyros ID
00000001 01 = Model ID
01010000 50 = SubID
00011001 19 = SubID (Hard Disk Recorder Control)
00000000 00 = SubID
00000000 00 = SubID (Start/Stop Control)
0ddddddd dd = data dd=00H:Start, 01H:Stop, 02H:Pause
11110111 F7 = End of Exclusive
Controls start/stop of the audio song, but this is not synchronized with the MIDI
song.
