79
Tyros3
Start-up screen (normal state) Start-up screen (when an error is detected)
“SwErr”
(A panel switch is being pressed. Displays up to two codes for panel switch held down in four fi gures in hexadecimal notation.)
“[DIMM] : No Device”
(No DIMM is installed.)
“[HDD] : No Device”
(No HDD is installed.)
2-1: How to carry out tests
1) When the test program is started,
“TEST”
will be displayed.
2) To increase test item number: Press the [TEMPO+] button or turn the [DATA ENTRY] dial clockwise. (Fig. 1)
To decrease test item number: Press the [TEMPO–] button or turn the [DATA ENTRY] dial counterclockwise. (Fig. 1)
To execute the test: Press the [START/STOP] button once. (Fig. 1)
Indication of "--" underneath of each test items is shown as progressing the test and in case of asterisks "
*
" is shown as
progress bar when the test takes time such as "Flash Check1,2", "Wave ROM Check 2" etc.
• If the test result is OK:
Press the [START/STOP] button again to go back to the item selection display. (Fig. 1)
• If the test result is NG:
Press the lowest key (C1) on the keyboard or the [DEMO] button to go back to the item selection display. (Fig. 1)
([START/STOP] button is ineffective in case of NG)
ＴＥＳＴ
Ｄｅｖｉｃｅ Ｃｏｎｎｅｃｔｉｏｎ Ｃｈｅｃｋ
［ＤＩＭＭ］：Ｄｅｖｉｃｅ ｆｏｕｎｄ
［ＨＤＤ ］：Ｄｅｖｉｃｅ ｆｏｕｎｄ
ＴＥＳＴ
ＳｗＥｒｒ：０Ａ０１，０Ａ０２
Ｄｅｖｉｃｅ Ｃｏｎｎｅｃｔｉｏｎ Ｃｈｅｃｋ
［ＤＩＭＭ］：Ｎｏ Ｄｅｖｉｃｅ
［ＨＤＤ ］：Ｎｏ Ｄｅｖｉｃｅ
To Next Page
