Yamaha TRS-MS02 - Test Program Item List (Continued); Tone Generator Sound Checks

85
Tyros3
Test 9
Function: Sound check of the Tone Generator 1
Description:
Sequentially outputs sounds starting from lower keys by
switching the channel of the sound source at the SWP51B
Master side for checking sound generator and sound. Check
that there is no abnormal sounds or noise.
Displayed Message:
Selected screen
When a sound is being produced.
When the checking is fi nished.
Supplement:
Sound producing keyboard range is 32 notes from C2 to G4.
Number of sounds is 64.
Test 10
Function: Sound check of the Tone Generator 2
Description:
Sequentially outputs sounds starting from lower keys by
switching the channel of the sound source at the SWP51B
Slave side for checking sound generator and sound. Check
that there is no abnormal sounds or noise.
Displayed Message:
Selected screen
When a sound is being produced.
When the checking is fi nished.
Supplement:
Sound producing keyboard range is 32 notes from C2 to G4.
Number of sounds is 64.
００９：ＴＧ １ Ｃｈｅｃｋ
−−
００９：ＴＧ １ Ｃｈｅｃｋ
Ｅｎｄ
００９：ＴＧ １ Ｃｈｅｃｋ
Indications during Execution
Circuit
Board
Location Name in Circuit Diagram
TG1 Check -- DM IC505 SWP51B MASTER
TG2 Check -- DM IC506 SWP51B SLAVE
０１０：ＴＧ ２ Ｃｈｅｃｋ
−−
０１０：ＴＧ ２ Ｃｈｅｃｋ
Ｅｎｄ
０１０：ＴＧ ２ Ｃｈｅｃｋ
Indications during Execution
Circuit
Board
Location Name in Circuit Diagram
TG1 Check -- DM IC505
SWP51B MASTER
TG2 Check -- DM IC506 SWP51B SLAVE
