4 - 29
ENG
CLUTCH
CLUTCH
LS
E
E
E
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)
T
R
.
.
70 Nm (7.0 m
•
kg, 50 ft
•
lb)
E
New
E
E
2
3
6
7
8
7
10
9
11
13
14
16
25
4
5
20
20
19
18
17
27
28
29
26
30
21
24
23
22
12 15
31
1
New
T
R
.
.
5 Nm (0.5 m
•
kg, 3.6 ft
•
Ib)
(3)
Extent of removal:
1
Friction plate and clutch plate removal
2
Clutch housing removal
3
Clutch removal
Extent of removal Order Part name Q’ty Remarks
CLUTCH REMOVAL
Preparation for removal Brake pedal and footrest assem-
bly
Refer to “ENGINE REMOVAL” section.
1 Clutch adjuster cover 1
2 Clutch adjuster locknut 1
3 Crankcase cover (right) 1
4 Dowel pin 2
5 Gasket 1
6 Clutch adjuster 1
7 Shift guide 2
8 Pawl holder 1
9 Shift arm 1
10 Pressure plate 1
2
1
3
To Next Page
