Yamaha VF115 - Neutral Interlock Trigger; Free Accelerator

Components
28
EMU40631
Neutral interlock trigger
The neutral interlock prevents the remote
control lever from accidentally being moved
forward or rearward from the neutral position.
To move the remote control lever forward or
rearward from the neutral position, pull the
neutral interlock trigger up, and then move
the remote control lever.
EMU26234
Free accelerator
To open the throttle without shifting into ei-
ther forward or reverse, push the free accel-
erator button and move the remote control
lever.
TIP:
 The free accelerator button can only be
pushed when the remote control lever is in
the neutral position.
 After the button is pushed, the throttle be-
gins to open after the remote control lever
is moved at least 35°.
 After using the free accelerator, return the
remote control lever to the neutral position.
The free accelerator button will return auto-
6. Fully open
1. Neutral “ ”
2. Forward “ ”
3. Reverse “ ”
4. Fully closed
5. Throttle
6. Fully open
1. Neutral interlock trigger
N
1
F
6
5
2
R
3
35°
35°
5
4
6
4
1
1. Free accelerator button
2. Fully closed
3. Fully open
1. Free accelerator button
2. Fully closed
3. Fully open
1
N
2
3
35°
3
1
2
N
