Trouble Recovery
87
Q. Are weeds or other foreign material tan-
gled on propeller?
A. Remove and clean propeller.
Q. Are outboard motor mounting bolts loose?
A. Tighten bolts or have serviced by a
Yamaha dealer.
Q. Is steering pivot loose or damaged?
A. Have serviced by a Yamaha dealer.
EMU29435
Temporary action in emergen-
cy
EMU29442
Impact damage
EWM00871
The outboard motor can be seriously
damaged by a collision while operating or
trailering. Damage could make the out-
board motor unsafe to operate.
If the outboard motor hits an object in the wa-
ter, follow the procedure below.
(1) Stop the engine immediately.
(2) Check the control system and all compo-
nents for damage. Also, check the boat
for damage.
(3) Whether damage is found or not, return
to the nearest harbor slowly and careful-
ly.
(4) Have a Yamaha dealer check the out-
board motor before operating it again.
EMU46603
Replacing fuse
EWM00632
Substituting an incorrect fuse or a piece of
wire could allow excessive current flow.
This could cause electric system damage
and a fire hazard.
If a fuse has blown, replace the fuse accord-
ing to the following procedure.
(1) Turn the main switch to the ā ā (off)
position.
(2) Remove the fuse box cover.
(3) Remove the fuse with a fuse puller, and
then replace it with a spare one of the
proper amperage.
1. Fuse box cover
2. Fuse puller
3. Main switch / PTT switch fuse (20 A)
4. Electric throttle valve fuse (10 A)
5. Fuel pump fuse (15 A)
6. Starter relay fuse (30 A)
7. Ignition coil / Fuel injector / Variable cam-
shaft timing / ECM (Electronic Control Mod-
ule) fuse (30 A)
8. Engine main fuse (50 A)
9. Spare fuse (10 A, 15 A, 20 A, 30 A)
10.Spare engine main fuse (50 A)
