8-21
8
6. Check the oil filler bolt gasket for dam-
age, and replace it if necessary.
7. Install the differential gear oil filler bolt
and its gasket, and then tighten the bolt
to the specified torque.
8. Check for oil leakage. If oil leakage is
found, check for the cause.
EBU32990
Coolant
The coolant level should be checked before
each ride.
Checking the coolant level
1. Park the vehicle on a level surface.
2. Check the coolant level in the coolant
reservoir when the engine is cold as the
coolant level varies with engine tempera-
ture.
The coolant should be between the minimum
and maximum level marks.
3. If the coolant is at or below the minimum
level mark, remove the coolant reservoir
cap, add coolant to the maximum level
mark, install the reservoir cap.
Tightening torque:
Differential gear oil filler bolt:
23 N·m (2.3 kgf·m, 17 lb·ft)
1. Coolant reservoir cap
2. Maximum level mark
3. Minimum level mark
UB5F7AE0.book Page 21 Tuesday, March 28, 2017 12:02 PM
