8-32
8
EBU32450
Cleaning the spark arrester
EWB03370
Hot exhaust system may cause burns. To
avoid burns or fires, make sure that the en-
gine is stopped and the exhaust system is
cool before cleaning the spark arrester. Do
not start the engine while cleaning the ex-
haust system.
1. Remove the tailpipe bolts.
2. Remove the tailpipe by pulling it out of
the muffler, and then remove the gasket.
3. Tap the tailpipe lightly, and then use a
wire brush to remove any carbon depos-
its from the spark arrester portion of the
tailpipe and inside of the tailpipe housing.
1. V-belt case drain plug
1. Tailpipe bolt
UB5F7AE0.book Page 32 Tuesday, March 28, 2017 12:02 PM
