EAU26320
SPECIFICATIONS
8-2
Caster angle
24.00 degree
Trail
70.0 mm (2.76 in)
Front tire
Type
Tubeless
Size
90/90-10 41J
Manufacturer/model
MAXXIS / C-922
Rear tire
Type
Tubeless
Size
90/90-10 41J
Manufacturer/model
MAXXIS / C-922
Loading
Maximum load
77 kg (170 lb)
Tire air pressure (measured on cold
tires)
Loading condition
0-77 kg (0-170 lb)
Front
150 kPa (1.50 kgf/cm2, 22 psi, 1.50 bar)
Rear
175 kPa (1.75 kgf/cm2, 25 psi, 1.75 bar)
Front wheel
Wheel type
Cast wheel
Rim size
J10 x MT2.15
Rear wheel
Wheel type
Cast wheel
Rim size
J10 xMT 2.15
Front brake
Type
Drum brake
Operation
Right hand operation
Rear brake
Type
Drum brake
Operation
Left hand operation
Front suspension
Type
Telescopic fork
Spring/shock absorber type
Coil spring/oil damper
Wheel travel
59.0 mm (2.32 in)
Rear suspension
Type
Unit swing
Spring/shock absorber type
Coil spring/oil damper
Wheel travel
54.0 mm (2.13 in)
Electrical system
Ignition system
CDI
Charging system
AC magneto
Battery
Model
GTX5L-BS
Voltage, capacity
12 V, 4.0 Ah
Headlight
Bulb type
Halogen bulb
Bulb voltage, wattage x quantity
Headlight
12 V, 35 W/35.0 W x 1
Tail/brake light
12 V, 5.0 W/21.0 W x 1
Front turn signal light
12 V, 10.0 W x 2
Rear turn signal light
12 V, 10.0 W x 2
License plate light
12 V, 5.0 W x 1
Meter lighting
12 V, 1.7 W x 2
High beam indicator light
12 V, 1.7 W x 1
Turn signal indicator light
12 V, 1.7 W x 2
Coolant temperature warning light
14 V, 3.0 W x 1
Fuse
Fuse
7.5 A
