3-11
INSTRUMENT AND CONTROL FUNCTIONS
3
To store a helmet in the storage com-
partment, place the helmet upside-
down with the front facing forward.
NOTE:
8 Some helmets cannot be stored
in the storage compartment
because of their size or shape.
8 Do not leave your scooter unat-
tended with the seat open.
EAU00320
Carrier
EW000032
w
8 Do not exceed the load limit of
3 kg (7 lb) for the carrier.
8 Do not exceed the maximum
load of 75 kg (165 lb) for the
vehicle.
1
1. Carrier

Yamaha VINO YJ50RP Specifications

General

Displacement	49cc
Bore x Stroke	38.0mm x 43.6mm
Compression Ratio	12.0:1
Starting System	Electric and Kick
Final Drive	V-Belt
Front Suspension	Telescopic fork
Rear Suspension	Unit swing
Front Brake	Drum
Rear Brake	Drum
Front Tire	90/90-10
Rear Tire	90/90-10
Wheelbase	1, 160mm
Engine Type	4-stroke, SOHC
Ignition	TCI
Transmission	Automatic
