Yamaha WaveRunner EX 2021 - Location of Main Components

Description
27
EJU31012
Location of main components
Exterior
1 2 4 5
5
8 9
3
7 3
13 12 11 10
6
1 Hood
2 Handlebar
3 Footwell
4 Seat (page 44)
5 Pull-up cleat (EX LIMITED) (page 46)
6 Boarding platform
7 Fuel filler cap (page 50)
8 Handgrip (page 44)
9 Reboarding grip (page 45)
10 Sponson
11 Gunwale
12 Cooling water pilot outlet (page 33)
13 Bow eye (page 46)
