Description
30
Engine compartment
8
3
10
11
4
2
1
56
7
9
1 Water separator (page 33)
2 Fuel tank
3 Air filter case
4 Flushing hose connector (page 80)
5 Oil tank filler cap/Dipstick (page 52)
6 Oil tank
7 Battery (page 60)
8 Fuse box
9 Spark plug/Ignition coil
10 Fire extinguisher holder (page 49)
11 Seat storage compartment (page 48)
