Watercraft operation
34
TIP:
If the RiDE lever is squeezed while the throttle
lever is squeezed, the watercraft will slow
down, and once stopped, move in reverse.
To shift into neutral from forward:
(1) Release the throttle lever.
(2) Lightly squeeze and release the RiDE le-
ver. The “N” (neutral) shift indicator will
be displayed.
TIP:
If the RiDE lever is squeezed continuously,
the reverse gate will move to the reverse po-
sition.
EJU43161
Electric trim system
The electric trim up switch and electric trim
down switch are located at the left handlebar
grip and are operated to change the vertical
angle of the jet thrust nozzle, which adjusts
the trim angle of the watercraft. The switches
can be operated only when the engine is run-
ning.
There are 5 positions: neutral, 2 bow-down
positions (a) and (b), and 2 bow-up positions
(c) and (d).
Bow-down positions (a) and (b)
The bow will go down, causing the trim angle
to decrease.
1 “N” (Neutral position)
1
1 Electric trim up switch
2 Electric trim down switch
1
2
(d)
(c)
(b)
(a)
(d)
(c)
(b)
(a)
UF2T75E0.book Page 34 Thursday, May 21, 2015 9:30 AM

Yamaha WaveRunner FX HO 2016 Specifications

General

Displacement	1812 cc
Compression Ratio	11.0:1
Fuel Delivery System	Electronic Fuel Injection (EFI)
Horsepower	180 hp
Starter System	Electric
Lubrication System	Wet Sump
Engine Type	4-stroke, 4-cylinder
Fuel Capacity	18.5 gal
Rider Capacity	3 persons
Fuel Type	Regular unleaded
Pump Type	155 mm
Bore x Stroke	86mm x 78mm
Cooling System	Water-cooled
Hull Material	Fiberglass
Color Options	Black
Top Speed	65 mph
