Equipment operation
38
EJU40334
Equipment
EJU31037
Seat
The seat is removable.
Remove the seat to access the engine com-
partment.
VXS:
VXR:
To remove the seat:
(1) Pull the seat latch up, and then lift up the
rear of the seat.
(2) Pull the seat rearward and remove it.
To install the seat:
(1) Insert the projections on the front of the
seat into the stays on the deck.
1 Seat latch
UF2M73E0.book Page 38 Friday, August 2, 2013 11:28 AM
To Next Page
