ORIGINAL

INSTRUCTIONS

ORIGINAL BETRIEBSANLEITUNG

DEUTSCHE ÜBERSETZUNG AUS DEM ENGLISCHEN

DRIVE UNIT • DISPLAY UNIT • BATTERY PACK • BATTERY CHARGER

ANTRIEBSEINHEIT • ANZEIGEEINHEIT • AKKUPACK • AKKULADEGERÄT

MODELLJAHR // MODEL YEAR 2016

DEUTSCH // ENGLISH

Table of Contents

Questions and Answers

V
Veronica FreemanAug 16, 2025
Why is pedaling so difficult on my Yamaha WINORA Y420.X?
- B
  Brian CampbellAug 17, 2025
  There could be several reasons why pedaling your Yamaha Bicycle feels difficult. First, make sure the display unit is powered on by pressing the power switch. Then, check if the battery pack is correctly installed and charged. If the bicycle has been stationary for more than 5 minutes, try turning the power on again. If you are riding uphill or carrying a heavy load in hot weather, it might be a safeguard to prevent overheating; shift to a lower gear. Low air temperature can also affect performance, so store the battery indoors before use in winter. Ensure the display is set correctly and stop charging the battery while it's mounted on the bicycle.
L
Lisa HillAug 19, 2025
What to do if my Yamaha WINORA Y420.X Bicycle drive unit turns on and off while riding?
- C
  Cynthia HermanAug 20, 2025
  If the drive unit on your Yamaha Bicycle is turning on and off while you're riding, check that the battery pack is correctly installed and locked in place. If the problem persists, it could indicate a loose connection at the battery pack terminals or wires, and you should have an authorized dealer inspect your bicycle.
U
uaguilarAug 22, 2025
What to do if traveling range has decreased on Yamaha WINORA Y420.X?
- R
  Rhonda BakerAug 22, 2025
  If you notice that the traveling range of your Yamaha Bicycle has decreased, ensure that you are fully charging the battery pack until it reaches full capacity. Low temperature conditions can also reduce the range; storing the battery pack indoors before use can help. If the battery pack is old, it may be worn out and need replacement.
E
Edward MorrisAug 25, 2025
What to do if Yamaha Bicycle cannot charge?
- G
  Gregory WellsAug 26, 2025
  If your Yamaha Bicycle is not charging, first ensure the power plug is firmly connected and the charging plug is properly inserted into the battery pack; reconnect and try again. Also, check if the residual battery capacity lamps are lit, review the charging method, and try again. If it still doesn't charge, the battery charger may be malfunctioning. Make sure the battery charger or battery pack contact terminals are clean and dry; if dirty or wet, remove the battery pack and charger plug, clean the terminals with a dry cloth or cotton swab, and then reconnect.
D
Daniel BerryAug 27, 2025
What to do if power is not supplied to my Yamaha Bicycle?
- X
  xorozcoAug 28, 2025
  If your Yamaha Bicycle is not receiving power, first ensure that the display unit is turned on by pressing the power switch. If you are using a USB device, make sure it complies with USB 2.0. Check that the USB cable is firmly connected. Also, inspect the USB receptacle and plug for dirt or moisture; disconnect the cable, clean any dirt or water, and reconnect.
L
Laura DavisAug 30, 2025
How to fix Yamaha WINORA Y420.X display unit shuts down immediately after switching the power on?
- M
  Mr. Robert AndersonAug 30, 2025
  If the display unit on your Yamaha Bicycle shuts down immediately after being switched on, the bicycle's battery pack connection terminals may be dirty. Remove the battery pack, clean the terminals with a dry cloth or cotton swab, and then reinstall the battery pack.
D
Derek RiveraSep 2, 2025
What happens if the battery charger becomes hot for Yamaha WINORA Y420.X Bicycle?
- S
  Sarah SandersSep 2, 2025
  It is normal for the battery charger of your Yamaha Bicycle to become somewhat warm during charging. However, if the battery charger is too hot to touch, unplug it, allow it to cool down, and then consult an authorized dealer.
R
Ryan GarciaSep 5, 2025
What to do if after charging the battery capacity indicator lamps do not light up on Yamaha WINORA Y420.X?
- K
  Kristin WhiteSep 5, 2025
  If, after charging your Yamaha Bicycle, the battery capacity indicator lamps do not light up when the button is pressed, try charging the battery pack again. This can happen if the charger plug was unplugged or the battery pack was removed during charging. Also, if you started charging the battery pack when it was at a high temperature (e.g., immediately after use), move the bicycle to a location where the battery temperature is between 0–30 °C, and then start charging again.
B
Brooke DrakeSep 7, 2025
What to do if the charging connector on the Yamaha WINORA Y420.X Bicycle battery pack is wet?
- B
  Barbara WatersSep 8, 2025
  Clean and dry the charging connector and charging plug on your Yamaha Bicycle. After that, connect the charging plug to the charging connector.
R
Robert ClineSep 10, 2025
What does it mean if both side lamps are flashing simultaneously on my Yamaha Bicycle?
- D
  Dawn HarperSep 12, 2025
  If both side lamps are flashing simultaneously on your Yamaha Bicycle, the battery pack protection feature has been activated, and the system cannot be used. Replace the battery pack at an authorized dealer as soon as possible.

Summary

Introduction to Yamaha e-Bike Systems

First Steps After Purchase

Understanding the E-Bike Systems

Available Assist Modes

Explains available assist modes like High-Performance, Standard, Eco, and Off.

Comprehensive Safety Information

Battery Charger Safety Precautions

Crucial safety precautions for using and handling the battery charger.

Battery Pack Safety Guidelines

Important safety guidelines for handling and using the battery pack.

General Riding Safety Advice

Safety advice for operating the e-bike and preventing accidents.

Instrument and Control Functions

Display Unit (LCD) Overview

Display Mounting and Power Control

Assist Mode Display and Speedometer

Battery Capacity and Clock Displays

Function Display Options Overview

Headlight, Pushing Assist, and Settings

Battery Pack and Charging Procedures

Appropriate Charging Environments

Charging the Battery Pack (Mounted)

Step-by-step instructions for charging the battery while mounted on the bike.

Removing and Charging the Battery

Procedures for removing the battery and charging it separately.

Mounting the Battery Pack on Bicycle

Reading the Charging Status Indicators

Checking Residual Battery Capacity

LCD Display Battery Capacity

Indicator Lamp Battery Capacity

Troubleshooting Common Issues

Pedaling Difficulties and Assist Problems

Common causes and solutions for difficult pedaling or lack of assist.

Drive Unit and Display Issues

Troubleshooting for problems with the drive unit and display shutdown.

Reduced Traveling Range

Pushing Assist and USB Power Issues

Battery Charging Problems

Solutions for issues like inability to charge or flashing indicator lamps.

Contact Faults and Wet Connectors

Addressing issues related to terminal contact faults and wet connectors.

Pack Protection and Charger Issues

Troubleshooting for battery protection activation and charger malfunctions.

Technical Specifications

Warranty and Guarantee Information
