PERIODIC MAINTENANCE AND MINOR REPAIR
6-8
6
To install the panel
1. Place the panel in the original posi-
tion, install spacer, and then install
the bolts.
2. Install the seat.
EAUM1710
Panel B
To remove the panel
1. Remove the seat. (See page
3-12.)
2. Remove the bolt, and then pull the
panel off at the areas shown.
To install the panel
1. Place the panel in the original posi-
tion, and then install the bolt.
2. Install the seat.
1. Bolt
2. Spacer
1. Bolt
