Yamaha XVS950CU - Right View

DESCRIPTION
2-2
2
EAU10420
Right view
1 2 3 4 5 6 7 8
910
1. License plate light (page 6-30)
2. Tail/brake light (page 6-29)
3. Battery (page 6-25)
4. Rear brake fluid reservoir (page 6-19)
5. Air filter element (page 6-13)
6. Fuel tank cap (page 3-12)
7. Main switch (page 3-2)
8. Steering lock (page 3-15)
9. Engine oil filter cartridge (page 6-10)
10.Brake pedal (page 3-11)
