PERIODIC MAINTENANCE AND ADJUSTMENT
6-29
6
5. Install the bulb cover, and then
connect the coupler.
When installing the headlight bulb cov-
er, make sure the “TOP” mark faces up-
wards.
6. Install the headlight unit by install-
ing the screws.
7. Have a Yamaha dealer adjust the
headlight beam if necessary.
EAU24181
Tail/brake light
This model is equipped with an LED-
type tail/brake light.
If the tail/brake light does not come on,
have a Yamaha dealer check it.
EAU24213
Replacing a turn signal light
bulb
1. Remove the turn signal light lens
by removing the screws.
2. Remove the burnt-out bulb by
pushing it in and turning it counter-
clockwise.
1. “TOP” mark
1. Screw
2. Turn signal light lens
