SPECIFICATIONS
8-2
8
5th:
1.042 (25/24)
Chassis:
Frame type:
Double cradle
Caster angle:
29.00 °
Trail:
130 mm (5.1 in)
Front tire:
Type:
Tubeless
Size:
100/90-19M/C 57H
Manufacturer/model:
BRIDGESTONE/EXEDRA G721 F
Rear tire:
Type:
Tubeless
Size:
150/80B16M/C 71H
Manufacturer/model:
BRIDGESTONE/EXEDRA G722 F
Loading:
Maximum load:
202 kg (445 lb)
(Total weight of rider, passenger, cargo and
accessories)
Tire air pressure (measured on cold
tires):
Loading condition:
0–90 kg (0–198 lb)
Front:
225 kPa (2.25 kgf/cm², 33 psi)
Rear:
250 kPa (2.50 kgf/cm², 36 psi)
Loading condition:
90–202 kg (198–445 lb)
Front:
250 kPa (2.50 kgf/cm², 36 psi)
Rear:
280 kPa (2.80 kgf/cm², 41 psi)
Front wheel:
Wheel type:
Cast wheel
Rim size:
19M/C x MT2.50
Rear wheel:
Wheel type:
Cast wheel
Rim size:
16M/C x MT3.50
Front brake:
Type:
Single disc brake
Operation:
Right hand operation
Specified brake fluid:
DOT 4
Rear brake:
Type:
Single disc brake
Operation:
Right foot operation
Specified brake fluid:
DOT 4
Front suspension:
Type:
Telescopic fork
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
120.0 mm (4.72 in)
Rear suspension:
Type:
Swingarm
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
70.0 mm (2.76 in)
Electrical system:
Ignition system:
TCI
Charging system:
AC magneto
Battery:
Model:
YTZ14S
Voltage, capacity:
12 V, 11.2 Ah
Headlight:
Bulb type:
Halogen bulb
Bulb voltage, wattage × quantity:
Headlight:
12 V, 60.0 W/55.0 W × 1
Tail/brake light:
LED
Front turn signal light:
12 V, 21.0 W × 2
