Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
128
7E)
• 1:1 Connection
• 1:n Connection
Signal name
SDA
RDB
SG
ERA
SDB
ERB
CSB
RDA
CSA
Display
Shield
Connector for the host side
communication connection
Signal name
RDB
SDB
SG
RDA
SDA
Pin
14
12
15
13
11
Display side
Terminal block
Signal name
SDA
RDB
SG
ERA
SDB
ERB
CSB
RDA
CSA
Display
Shield
Connector for the host side
communication connection
Shield
Connector for the host side
communication connection
Signal name
RDB
SDB
SG
RDA
SDA
Pin
14
12
15
13
11
Signal name
RDB
SDB
SG
RDA
SDA
Pin
14
12
15
13
11
Display side
Terminal block
