Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
127
7D)
• 1:1 Connection
• 1:n Connection
CA4-ADPONL-01
Display
Signal name
RDB
7
RDA
2
SDB
8
9
TERMTX
SDA
FG
3
TERMRX1
SG
5
D-Sub 9 pin (plug)
Pin
Shell
Shield
Connector for the host side
communication connection
Signal name
RDB
SDB
SG
RDA
SDA
Pin
14
12
15
13
11
User-created cable
CA4-ADPONL-01
Display
Signal name
RDB
7
RDA
2
SDB
8
9
TERMTX
SDA
FG
3
TERMRX1
SG
5
D-Sub 9 pin (plug)
Pin
Shell
Shield
Connector for the host side
communication connection
Shield
Connector for the host side
communication connection
Signal name
RDB
SDB
SG
RDA
SDA
Pin
14
12
15
13
11
Signal name
RDB
SDB
SG
RDA
SDA
Pin
14
12
15
13
11
User-created cable
