40
VG3511-8F
8
. Specifications
Model VG3511-8F
Description High speed cylinder bed 3-needle interlock stitch machine with left hand trimming mechanism
Dimensions 470 ㎜（L）× 220 ㎜（W）× 405 ㎜（H)
Circumference
of Cylinder
340 ㎜
Weight 41.5 kg
Stitch Type ISO 406, 407, 602, 605
Application Hemming operation of knitted fabric for lightweight material
Sewing Speed Up to 5500 rpm (during intermittent operation)
1.4 - 3.6 ㎜
Stitch Length Number of stitches per inch(25.4 ㎜ ) 7 - 18 stitches
per 30 ㎜ 8 - 21 stitches
Needle System UY × 128GAS #10 - #14 (standard: #10)
Needle Distance 3-needle: 4.8 ㎜ , 5.6 ㎜ , 6.4 ㎜
Needle Stroke 31 ㎜
Upper knife stroke 3.0 - 4.0 ㎜
Suctioning chips Ventury or vacuum system
Presser Foot Lift
For 5.6 ㎜ of needle distance
with spreader: 5.5 ㎜ , without spreader: 7.0 ㎜
Feed Regulation By adjusting screw (available for micro adjustment)
Dierential Ratio
Standard: 1 : 0.7 - 1 : 1.4
1 : 1.1 - 1 :2 (stitch length is 2.5 mm or less in max. normal dierential)
Dierential Feed
Regulation
Micro adjustment by adjuster
Adjustable by moving external lever even during operation
Lubrication Lubrication automatically by trochoid-shaped pump
Lubricating Oil YAMATO SF OIL No.28
Capacity of
Oil Reservoir
800 ml
Installation Table top type
Compliance with
Regulator
CE Marking
Noise
declaration
Lp
A
=83.6dB（5,500sti/min) according to ISO 10821-C6.2-ISO 11204 GR2
Table 6
