X K 3 1 9 0A22
Chapter 1. Main specification
1. Model: Weighing Indicator XK3190-A22
2. Accuracy: Grade , n=3000
3. A/D conversion method: Δ-
4. Sampling speed: 10 times/second
5. Load cell sensitivity: 1.53mV / V
6. Nonlinearity: 0.001%F.S
7. Load Cell Excitation Voltage: DC5V
8. Full load temperature coefficient: 2.5 PPM/
9. Division: 1/2/5/10/20/50 optional
10. Maximum connection number of load cell: 4 load cells at 350 (with long distance compensation )
11. Keypad: mild touch off keypad, 5 function keys
12. Communication interface(optional): RS232CBaud rate: 1200/ 2400/ 4800/ 9600 optional
13. Display: 6 bits LED display, 6 status indicating annunicator
14. Power supply: rechargeable battery DC6V/4AH (bAt-Lo will be showed as alarm when the voltage
is below 5.3V)
15. Operating temperature and humidity: 040℃;90%RH
16. Storage temperature: -2555
( 1 )
