X K 3 1 9 0－A22
The accumulate function will only effect again after the displayed weight back to zero. When the
accumulated weight is displayed, you can press [FUNC] to clear them in the memory, press [ # ] to
return the weighing mode. To check the accumulated weight of the memory, keep the scale
platform empty and press [*] to display the accumulated weight.
3.6 PARAMETER SETUP
In weighing mode, press [FUNC] to enter the user setting mode (mode P), it will display P-SET,
there are 10 modes from P1 to P10, press [*] to select the mode and press [TARE] to select the
parameter, press [#] to save and quit. The parameter is described as following:
1、P1 x kg Lb switch
x=1: Kg display
x=2: Lb display
2、P2 x communication address
x=1: 01
x=2: 02
x=… …
x=23： 23
x=24： 24
3、P3 x baud rate setting
x＝9600: baud rate 9600bps；
x＝4800: baud rate 4800bps；
x＝2400: baud rate 2400bps；
x＝1200: baud rate 1200bps。
please refer to appendix for bidirectional communication method
4、P4 x digital filter intensity
x=1: highest
x=2: higher
x=3: high
x=4: low
x=5: lower
x=6: lowest
5、P5 x RS232 output mode option
x=1: no transmission（RS232 stop）
x=2: continuous transmission
( 7 )
