YARD Commander 125LB - Page 19

- 19 -
Ref# Drawing No. Description Qty
1 N512-00020 Hopper 1
2 9302-06000-DG Big Flat Washer Ø6 16
3 9101-06040-DG Hex Bolt M6x40 15
4 N512-00026-DG R Pin Ø3 1
5 N512-00009 Bearing 2
6 N512-00021 Fixed Adjustable Plate 1
7 N512-00022 Active Adjustable Plate 1
8 N512-00023-DG Base for Spring 1
9 9206-06000-DG Hex Lock Nut M6 22
10 N512-00025-DG Spring 1
11
9206-08000-DG
Hex Lock Nut M8
3
12
9301-08000-002
Flat Washer Ø8
2
13
N512-00024-DG
Fixed Plate for Connecting Rod
1
14 N514-00004 Impeller 1
15 N560-80000 Wheel 2
16 9404-05035-DG Cotter Pin Ø5x35 2
17 9301-16000-DG Flat Washer Ø16 8
18 N575-00003 Screen 1
19 N514-00001-DG Axle 1
20 N570-00018 Inner Axle Bushing 2
21 N570-00011 Outer Axle Bushing 2
22 9504-05008-DG Rivet Ø5x8 2
23 N512-00001 Frame Tube Assembly 1
24 N512-00007 Pinion Gear 1
25 N514-00005-DG Swivel Axle 1
26 9110-04020-DG Screw M4x20 1
27 9402-03016-DG Spring Pin Ø3x16 1
28 N575-00009-DG Solid Linkage 1
29 9101-08075-DG Hex Bolt M8x75 1
30 N575-00004-DG Spacer 1
31 N575-20000 Fixed Crossover Tube 1
32
T680-00003
Plastic Cap
3
33
N576-01000
Support Tube
1
34
9101-06035-DG
Hex Bolt M6x35
2
35 N575-50000 Handle 1
Parts List
