ASSEMBLY AND PREPARATION
WARNING: Unplug the power cord before assembly.
NOTE: A Phillips type screw driver will be required for assembly of the pressure washer.
Follow these steps in conjunction with Fig. 1 & 2.
1. Insert the hose wheel handle (J) into the installation hole at the side of the hose wheel
and press in rmly until the handle lock into position. Fig. 3.
2. Insert the gun holder (K) into the slots in the side of the main body of the pressure
washer (L) and press down rmly until the brackets lock into position. Fig. 4.
3. Place a small amount of grease of or vasoline on the thread of the spray gun (E).
4. Screw the high pressure outlet hose (Fig. 5) to the spray gun (E) and secure. Fig. 5.
5. To use the lance, push the lance (C) or (D) into the spray gun (Fig. 13) and twist it to lock
into the position. Fig. 6.
6. To use the patio cleaner, push the patio cleaner (A) into the extension lance (B) and twist
it to lock into the position. Then push the extension lance (B) into the spray gun (Fig. 13)
and twist it to lock into the position. Fig. 7.
7. Screw the water inlet adapter (F) to the pressure washer. Fig. 8.
8. Attach your garden hose (not supplied) to the water inlet adaptor (F). Fig. 9.
Connect your garden hose to a COLD water tap and turn the water supply ON. Fig. 10.
Note： If the tap is not open sufciently or your mains water ow is too low then the
pressure washer will not work correctly.
CAUTION! Only connect the pressure washer to COLD water. Hot water will damage
the pressure washer.
9. Check that the ON/OFF switch is in the OFF position.
