22 23
TROUBLESHOOTING TECHNICAL DATA
WARNING! Faults that cannot be rectied with the help of the following table must
be referred to an authorised service centre.
Problem Possible cause Possible solution
Pressure washer
not running.
No Power. Check power outlet is turned ON.
Residual pressure in high
pressure hose.
Press the gun trigger on spray gun.
ON/OFF switch set to “0” OFF.
Set the ON/OFF switch to “I” ON
position.
Motor protection has
activated.
Allow to cool for 15 minutes.
Output pressure is
steady but too low.
High pressure hose is
damaged.
Change the high pressure hose.
Leaks in the high pressure
connections.
Hand tighten high pressure screw
connections.
Leaks in the
machine.
Internal leaks. Consult authorised service centre.
Hose connections loose.
Hand-tighten the water intake
adapter and the high pressure
hose screw connections.
Irregular operating
pressure.
Air in the inlet water hose.
Check the supply hose and hose
connection, replace if necessary.
The water lter is clogged. Clean the water lter.
Water supply hoses kinked. Straighten water supply hoses.
Inadequate water supply. Check the water supply ow.
The high pressure
washer operates
intermittently.
Power cable is damaged. Consult authorised service centre.
Internal loose electrical
connection.
Consult authorised service centre.
ON/OFF switch is defective. Consult authorised service centre.
The motor starts
but there is no build
up of pressure.
The water lter is clogged. Clean the water lter.
No Water.
Check that the water supply is
turned on and that there is no air in
the supply hose.
Model No. EW U19
Rated input voltage 230-240V~, 50 Hz
Rated input power 1800 W
Rated pressure 1334 PSI / 9.2 MPa
Max. pressure 2000 PSI / 13.8 MPa
Max inlet pressure 87 PSI / 0.6 MPa
Rated Flow rate 5.2 L/min
Max. ow rate 6.3 L/min
High pressure hose length 5 m
Cable Length 5 m
Pump type Aluminium
Weight 10.0 Kg
