10
N. Never ll fuel tank when engine is running or hot.
O. Stop the engine before re-fuelling.
P. Stop the engine and disconnect the spark plug wire If the tool starts
to vibrate abnormally (nd and remove the cause of the vibration
immediately).
Q. Reduce the throttle before turning o the engine.
R. The user is responsible for the safety of other people, animals and
objects in the working area. Keep people, children and domestic
animals at a safe distance while the tool is in use.
PREPARATION
BEFORE THE BRUSH CUTTER CAN BE USED IT REQUIRES
SOME ASSEMBLY.
INSTALLING THE GUARD
● With the 5 mm Hex key. Remove the
two screws from the top of the guard
and the one on the side of the cutting
head.
● Place the Bracket (H) on the top of the
shaft and reinsert and tighten the screw
in the cutting head.
● Hold the Guard (D) underneath the
bracket, insert the two screws through
the bracket in to the holes in the guard
and retighten rmly.
To Next Page
