11
FITTING THE BLADE
● Lock the shaft by Inserting the 5mm hex
key through the hole and into the blade
mounting boss as shown.
NOTE: The ange nut has a left hand thread.
● Remove the ange nut using the Spark
plug spanner (J) by turning it in a
clockwise direction.
● Remove the top ange and mount the
blade on the centre boss.
● Replace the ange and make sure that
the blade stays correctly mounted.
● Replace the ange nut.
● Tighten the ange nut rmly anti-clockwise.
● Remove the Hex key to unlock the shaft.
