12
TO USE THE LINE TRIMMER HEAD
● Lock the shaft by Inserting the 5mm hex
key through the hole and into the blade
mounting boss as shown.
NOTE: The ange nut and spindle have left hand
threads.
● Remove the ange nut using the Spark
plug spanner (J) by turning it in a clockwise
direction.
● Remove the top ange.
● Mount the line trimmer head onto the
spindle.
● Tighten the line trimmer head in
an anti-clockwise direction.
● On the underside of the guard, remove the
protective cover on the line cutting blade.
● Remove the hex key to unlock the shaft.
● Store the top ange and ange nut in a
safe place in case they are needed for
later use.
