SETTING THE CUTTING HEIGHT
As shown in Fig. 10
CAUTION! Adjust the cutting height only when the engine is not running.
NOTE: For shipping purposes the height adjustment position may not be adjusted to the cutting position.
Before operating the mower adjust cutting height to the normal cutting position.
Adjust the cutting height to suit your requirements. The middle position is suitable for most lawns.Raise the
wheels for low cut and lower the wheels for a high cut.
The cutting height is adjusted by individual wheel. To change the cutting height, squeeze the height
adjustment lever toward the wheel.
Move the wheel up or down to the desired position and release the lever to lock the wheel in position. Be
sure all the wheels are at the same height.
From position 1 to position 5, the cutting heights range from 1.25" to 3.75"' (32-95mm).
ASSEMBLY
3.75” (95 mm) 1.25”(32mm)
Fig.10
