7
Hotline: 1-866-902-9690
1 Self-propelled drive control bar
2 Upper handle
3 Engine start handle
4 Rope guide
5 Grass bag
6 Rear chute ap
7 Height-adjusting handle
8 Rear wheel
9 Side discharge chute (removable)
10 Side discharge cover
11 Front wheel
12 Cutting deck
13 Spark plug cover
14 Oil ller dipstick
15 Gas ller cap
16 Cord clip
17 Lower handle
18 Handle knob and bolt
19 Engine on/off control bar
PARTS LIST
Carefully remove the lawn mower from its packaging and check that the following parts are included:
A. Main mower deck (with upper handle) 1 pc
B. Side discharge chute 1 pc
C. Handle Knob and Bolt 4 sets
D. Grass bag with holder 1 pc
E. Engine Oil (SAE 30 15 o.z.) 1 pc
F. Lower handle bar 1 pc
G. Manual 1 pc
H. Cord clip 1 pc
I. Mulching plug (inside the mower) 1 pc
PARTS LIST
