NOTE: The USB port is only powered when the start key is in the ON position.
NOTICE!
Attempting to charge devices rated more than 2 amps could damage the USB charging port and/or
the mower.
WARNING!
Never use headphones or any electronic device, such as a smart phone or tablet, while operating
the mower. Distracted operation can result in an accident that could result in death or serious
personal injury to the operator or a bystander.
WARNING!
If any parts are damaged or missing, do not operate this lawn mower until the missing parts are
replaced. Failure to heed this warning could result in serious personal injury.
NOTICE!
Always recycle the packaging in accordance with local recycling programs.
WARNING!
This item requires a two-person lift to remove from the packaging. Make sure that you have sufcient
space to put the lawn mower down. Keep your feet apart so that you have a stable position, bend at
the knees and keep your back straight.
PARTS LIST
Carefully remove all parts from their packaging and check that the following parts are included. See Fig 2 &
Fig. 2A:
A. Seat Assembly with Safety Interlock Cable 1pc
Flange Nut (A) 2pcs
Bolt (B) 2pcs
B. Steering Column Assembly
Spring (C) 1pc
Washer (D) 1pc
Washer (E) 1pc
Flange Nut (F) 1pc
Bolt (G) 2pcs
Spring Washer (H) 2pcs
Washer (I) 2pcs
Upper Steering Shaft 1pc
Steering Column 1pc
Steering Column Cover 1pc
Steering Wheel 1pc
Steering Wheel Cover 1pc
C. Charger 1pc
D. Wrenches 2pcs
E. Mulch Cover 1pc
F. Key 3pcs
G. Wash-port Quick Coupler 1pc
H. Owner’s Manual 1pc
