14
1-866-902-9690
PARTS LIST
Fig. 2
A
C
D
E
F
HG
B
MANUAL
Fig. 2a
Flange Nut (A) Washer (E) Washer (D) Spring (C) Bolt (G),
Spring Washer (H),
Washer (I)
Flange Nut (A)Bolt (B)
Flange Nut (A)Bolt (B)
Note: Both Flange Nuts (A) and Bolt (B) are attached to seat for shipment.
