YARD KING PERFORMANCE 50562X89 - Page 41

50S62X89 MOTION DRIVE ASSEMBLY
KEY
NO.
1
2
3
4
5
6
7
8
9
1o
11
12
13
14
15
16
17
18
19
20
24
25
25
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
48
49
52
53
54
55
56
57
58
59
60
61
61-1
61-2
61-3
62
64
65
66
67
68
PART
NO.
180091
710205
94432-821
94433-821
710268
57072
710205
94422-821
57101
710205
694424
710238
710107
92132
71O343
694426
710119
710107
710108
94428
710281
710107
94430-821
710346
710657
710249
710345
710330
94417
710281
710107
710707
94815
94045
710142
710107
710333
710353
94568
335980
21544
91179
710140
694411
710098
710140
91179
91178
710140
710531
93248
93249
94756
342118
342117
338512
24582
52928
710351
95421
710088
36625
DESCRIPTION QTY
HYDRO PEERLESS 205-024 1
SCREW, 5/16-18X2.50 HHC 4
NUT, 5/16-18 WDFLLK (15X88) 4
TORQUE STRAP 1
TORQUE STRAP-LEFT 1
SCREW, 5/16-18X .75 WAHHI'AP 2
BOLT, CARR. 5/16-18X.63 2
NUT, 5/16-18 WDFLLK (15X88) 2
PEDAL ASSEMBLY 1
BOLT, 5/16-18X.75 CARR. 3
NUT, 5/16-18 WDFLLK (15X88) 3
ROD, PEDAL LINK (PEERLESS) 1
WASHER, .469X.72 (17X57) 1
COTTER PIN 30X20 1
ADJUSTING NUT 1/2-13 1
PIN, HAIR .38DIAX1.64LLG 1
ROD, HYDRO LINK 1
WASHER FLAT 1
PIN, COTTER .094DIAX.75 30X20 1
HAIR PIN (31X4) 1
ZINC ROD, DISCONNECT 1
FLATWASHER .344×.62X.06 1
PIN, COFFER .094DIAX.75 30X20 1
ARM, DISCONNECT 1
WASHER .388X.393 1
FLATWASHER .256X.75X.136 1
WASHER (18X32) 1
SCREW, 1/4-28X.75 1
SPRING, EXTENSION 1
CLUTCH ROD 1
WASHER, FLAT .344X.62X.06 1
PIN, COTFER .094DIAX.75 30X20 1
SPRING, CLUTCH 1
NUT, ADJUSTING 1
LATCH, PARK BRAKE 1
WASHER, FLAT .408X.81 1
COTTER PIN .094DIAX.75 30X20 1
SPRING, EXTENSION 1
SPRING, TENSION 1
PARK BRAKE CONTROL ROD 1
CAP, DUMP VALVE ROD 1
PEDAL, BRAKE/CLUTCH 1
PULLEY, IDLER 1
NUT, 3/8-16 HWDFLLK MACK 15X84 !
ASSY, BRACKET IDLER 1
BOLT, .50X.75 HHSH 3/8-16 9X39 1
NUT, 3/8-16 HWDFLLK MACK 15X84 1
PULLEY, IDLER 1
PULLEY, V-IDLER 3" 1
NUT, 3/8-16 HWDFLLK MACK 15X84 1
BELT, MOTION HYDRO 37X61 1
PEDAL, PAD SANDPAPER 1
PAD, TOE SANDPAPER 1
TIRE & RIM 22X10.5-12 2
RIM, CARL 2
TiRE 22X10.5-12 2
VALVE STEM 2
HUB CAP 2
KEY, SQUARE .187SQX2.25LG 2
WASHER, FLAT .760X l.25X.065 4
SPACER, .87x1.78 MURRAY 1!87x105 2
FLATWASHER .765X1.81X.059 2
RING, RETEX .57X.05TRU5133-75 2
41
