7
SECTION 6: ITEMS REQUIRED FOR ASSEMBLY
QTY DESCRIPTION
(1) Crowbar or Large Screwdriver
(1) Soft Hammer or Mallet
(2) 9/16" Wrenches*
(2) 1/2" Wrenches*
(1) 7/16" Wrench*
(1) 13/16” Wrench*
(1) 7/8” Wrench*
(1) Adjustable Wrench
(1) Screwdriver
(1) Pliers
(1) Knife
(1) Cutters
• Engine Oil
• Unleaded Gasoline
• Dexron III Automatic Transmission Fluid or
10W Non-Foaming Hydraulic Fluid
*Adjustable Wrenches may be used.
SECTION 7: UNPACKING
WARNING:
Exercise extreme caution
as parts are very heavy. Mechanical
handling equipment should be used, or
sufficient people to prevent injury.
1. Pry the top, sides and ends off crate using a
crowbar or large screwdriver.
2. Set panels aside to avoid tire punctures or
personal injury.
3. Remove and discard plastic bag that covers unit.
4. Remove wheels and small box from crate.
5. Cut and remove straps which secure parts to
bottom of crate. Unbolt parts which are bolted to
the bottom of the crate.
CONTENTS OF CRATE
• Reservoir Tank and Engine -Pump Assembly
• Wedge, Beam and Cylinder Assembly
• Tongue Assembly
• Wheels
• Hitch Assembly
• Beam Support/Latch Bracket
• Fenders
CONTENTS OF HARDWARE PACK
• 2 hub caps
• Log Splitter Operators Manual
• 4 bolts
• 4 lock washers
• 4 nuts
• Engine Owners Guide
