Yard Machines E765F - Page 19

19
Handle Assembly
REF.
NO.
PART
NO. DESCRIPTION
1 705-5234 Clutch Lever Assembly - RH
2 705-5233 Clutch Lever Assembly - LH
3 720-0274 Grip
4 784-5718 Control Panel Assembly
5 735-0199A Bumper Rubber
6 749-0910B Handle RH
7 749-0911B Handle LH
8 629-0058 Light Harness
9 731-1500 Pivot Rod Cover
10 747-0984 Pivot Rod
11 746-0778 “Z” Fitting
12 712-0121 Hex Jam Nut
13 746-0897 Auger Clutch Cable
14 746-0898 Drive Clutch Cable
15 712-3010 Hex Nut 5/16-18
16 736-0119 Lock Washer 5/16
17 750-1053 Spacer
18 726-0135 Nut Cap
19 710-0262 Carriage Bolt 5/16-18 x 1.5
20 726-0100 Push Rod Cap
21 720-0201A Chute Crank Knob
22 715-0138 Roll Pin
23 684-0022 Chute Crank Assembly
24 736-0242 Bell Washer .340 ID x .873 OD
25 747-0697 Eyebolt
26 735-0234 Rubber Grommet
27 720-0223 Grip
28 784-0388 Speed Selector Plate (2 Rev)
29 710-1652 Hex Washer Screw 1/4-20 x .625
30 710-1003 Hex Washer Screw #10 16 x .625
31 710-0599 Hex Washer Screw 1/4-20 x .50
32 712-0415 Hex Nut
33 725-1300 Headlight 18 Watt
34 731-1317 Headlight Cover
35 747-0904 Shift Lever
36 710-3015 Hex Cap Screw 1/4-20 x .75
37 712-3027 Hex Lock Nut 1/4-20
38 732-0733 Shift Lever Spring
39 710-0788 Hex Washer
40 784-5599 Handle Tab
41 710-3180 Hex Cap Screw 5/16-18 x 1.75
42 710-3008 Hex Cap Screw 5/16-18 x .75
43 736-0185 Flat Washer 3/8 ID x .738 OD
44 714-0104 Cotter Pin
45 712-0429 Hex Lock Nut 5/16-18
46 736-0159 Washer 5/16
47 731-0921 Upper Chute
48 720-0284 Knob 5/16-18
49 710-0276 Carriage Screw 5/16-18 x 1.0
50 710-0451 Carriage Bolt 5/16-18 x .75
51 731-1300A Lower Chute
52 712-3027 Hex Lock Nut 1/4-20
53 731-0851A Chute Flange Keeper
54 710-3015 Hex Cap Screw 1/4-20 x .75
REF.
NO.
PART
NO. DESCRIPTION
