Yard Machines E765F - Section 4: Contents of Hardware Pack

5
SECTION 4: CONTENTS OF HARDWARE PACK
Lay out the hardware according to the illustration for identification purposes. Part numbers are shown in parentheses.
(Hardware pack may contain extra items which are not used on your unit.)
A
ATTACHING THE HANDLES
B
ATTACHING THE HANDLE PANEL
D
ATTACHING THE CLUTCH CABLES
(2) Hex Jam Nuts
(712-0121)
(2) “Z” Fittings
(746-0778)
E
ATTACHING THE CHUTE ASSEMBLY
G
AUGER SHEAR BOLTS (SPARES)
F
ATTACHING THE CHUTE CRANK ASSEMBLY
ATTACHING THE SPEED SELECTOR PLATE
AND SHIFT LEVER
C
Hex Bolts
1/4-20 x 3/4” Long
(712-3015)
Hex Lock Nuts
Self-Tapping
Screws
1/4-20 x 1/2” Long
H
ATTACHING THE TRACK CONTROLS
Triggers
Control
746-0950
Track
Hex Bolts
(710-3180)
Handle Tabs
(784-5599)
Hex Bolts
(710-3008)
Lock Washers
(736-0119)
5/16-18 x 1-3/4” Long
5/16-18 x 3/4” Long
5/16” I.D.
Lock Washers
(736-0119)
Carriage Bolts
(710-0262)
5/16” I.D.
5/16” Thread
5/16-18 x 1-1/2” Long
Hex Nuts
(712-3010)
Shear Bolts
(710-0890A)
(712-0429)
Hex Lock Nuts
5/16” Thread
Hex Bolts
(710-3015)
Chute Flange
(731-0851)
Keepers
Hex Lock Nuts
1/4-20 x 3/4” Long
1/4-20 Thread
(712-3027)
Hair Pin Clip
(714-0104)
Hex Nut
(712-3010)
Cupped Washer
(736-0242)
5/16” I.D.
5/16” Thread
Flat Washers
(736-0185)
3/8” I.D. x 5/8” O.D.
(712-3027)
1/4-20 Thread
(710-0599)
