Yard Machines E765F - Page 21

21
Frame Assembly
REF.
NO.
PA RT
NO. DESCRIPTION
1 784-5684 Frame Cover
2 710-1652 Tap Screw, 1/4-20 x .625
3 748-0190 Spacer, .508 ID x .75 OD x .68
4 732-0264 Ext. Spring
5 712-0711 Jam Nut, 3/8-24
6 736-0105 Bell Washer, .401 x .87 x .063
7 684-0021 Friction Wheel Support Bracket Assembly
8 746-0898 Drive Cable, 39.88”
9 656-0012A Friction Disc
10 784-5689A Front Support Guide Bracket
11 713-0413 Ten-Tooth Sprocket
12 746-0897 Auger Cable, 44.75”
13 750-0997 Spacer, .675 ID x 1 OD x .23
14 711-1042 Hex Track Shaft
15 684-0042B Friction Wheel Assembly
16 736-0160 Flat Washer, .536 ID x .93 OD x .05
17 714-0474 Cotter Pin
18 741-0563 Ball Bearing
19 736-0242 Bell Washer, .34 ID x .872 OD
20 710-0538 Hex Cap Screw, 5/16-18 x .625
21 710-0857 Tap Screw, 1/4-20 x .75
22 736-0270 Bell Washer, .265 x .75 x .062
23 736-0176 Flat Washer, 1/4 ID x .93 OD x .12
24 741-0597 Hex Flange Bearing
25 710-0643 Hex Cap Screw, 5/16-18 x 1
26 748-0234 Shoulder Spacer
27 710-0604 Tap Screw, 5/16-18 x .625
28 684-0031 Frame Assembly
29 738-0924 Spacer
30 756-0625 Cable Roller
31 784-5688 Drive Cable Guide Bracket
32 710-0599 Tap Screw, 1/4-20 x .5
33 784-5590 Shift Frame Bracket
34 684-0014B Shift Rod Assembly
35 784-5687 Auger Cable Guide Bracket
36 710-0788 Tap Screw, 1/4-20 x 1
37 618-0063 Friction Wheel Bearing
38 718-0301A Friction Wheel Hub
39 735-0243 Friction Wheel Rubber
40 784-5617A Friction Plate
