23
Track Assembly
REF.
NO.
PA RT
NO. DESCRIPTION
1 720-0223 Grip
2 710-0604 Tap Screw, 5/16-18 x .625
3 784-5642 Track Lockout Plate
4 710-0157 Hex Cap Screw, 5/16-24 x .75
5 736-0242 Bell Washer, .34 ID x .872 OD
6 684-0038 Track Lock Handle Assembly
7 710-0459A Hex Cap Screw, 3/8-24 x 1.5
8 712-0214 Hex Nut, 3/8-24
9 748-0353A Lift Shaft Drive
10 750-0547 Spacer, .628 ID x .875 OD x .5
11 784-5609 Steering Cable Bracket
12 684-0009 Track Pivot Rod Assembly
13 712-0346 Jam Nut, 1/2-20
14 731-1292 Snow Track
15 736-0272 Flat Washer, .5 x 1 x .06
16 731-1538A Track Drive Wheel
17 631-0032 Track Idler Wheel
18 750-0995 Spacer, .51 ID x .75 OD x 1.67
19 738-0140 Shoulder Screw, .435 x .178-5/16 x .56
20 736-0406 Flat Washer, .442 x 1.38 x .06
21 750-0909 Spacer, .51 ID x 1 OD x 1.34
22 712-0429 Hex Nut, 5/16-18
23 618-0044 LH Dogg Assembly
24 684-0024 Idler Axle Assembly
25 710-1231 Eye Bolt, 5/16-18 x 3
26 784-5639 Track Side Plate
27 711-0911 Actuator Shaft
28 713-0233 Chain
29 618-0169 Track/Steering Shaft Assembly
30 683-0024 Track Hub Assembly
31 713-0437 Chain
32 741-0339 Flange Bearing
33 736-0287 Flat Washer, .793 x 1.24 x .06
34 611-0053 Axle Assembly
35 750-0904 Split Spacer, .514 x .630 x 1.59
36 618-0043 RH Dogg Assembly
37 750-0903 Split Spacer, .514 x .630 x 2.44
38 732-0209 Ext. Spring
39 710-0602 Tap Screw, 5/16-18 x 1
40 719-0295A Track Housing
41 746-0948 Steering Cable
42 746-0950 Steering Trigger
43 712-0127 Flange Nut
44 710-1233 Screw, #10-24 x 1.375
45 716-0114 Retaining Ring
46 618-0046 Carrier Assembly
47 717-1211 Ring Gear
48 716-0115 Retaining Ring
49 713-0414 13-Tooth Sprocket
50 711-0912 Track Steering Drive Shaft
51 736-0502 Flat Washer,.58 x 1.06 x .02
52 736-0336 Flat Washer, 5/8 x 1 x .03
53 715-0120 Spirol Pin, 3/16 x 1
54 717-1209 12-Tooth Gear
55 717-1210 18-Tooth Gear
