Blower Housing 26’’
REF.
NO.
PART
NO. DESCRIPTION
1 712-0116 Lock Jam Nut 3/8-24
2 756-0178 Flat Idler
3 784-5632 Auger Idler Arm
4 710-0459A Hex Cap Screw 3/8-24 x 1.50
5 738-0281 Shoulder Screw
6 736-0174 Wave Washer
7 732-0611 Extension Spring
8 712-3068 Hex Nut 5/16-18
9 712-3010 Hex Nut 5/16-18
10 736-0119 Lock Washer 5/16
11 05931 Bearing Housing
12 741-0309 Ball Bearing
13 710-0451 Carriage Bolt 5/16-18
14 705-5226 Reinforcement Chute
15 684-0040B 26” Housing Assembly
16 712-3010 Hex Nut 5/16-18
17 736-0119 Lock Washer 5/16
18 736-0242 Bell Washer
19 741-0475 Bushing
20 784-5647 Chute Crank Bracket
21 731-1379 Chute Adapter
22 712-0324 Hex Lock Nut 1/4-20
23 736-0463 Flat Washer
24 710-0451 Carriage Bolt
25 710-0703 Carriage Screw 1/4-20 x .75
26 710-0604 Hex Washer Screw 5/16-18
27 736-0169 Lock Washer 3/8
28 712-0798 Hex Nut 3/8-16
29 710-0451 Carriage Bolt 5/16-18 x .75
30 784-5580 Snow Shoe
31 736-0242 Bell Washer
32 712-3010 Hex Nut 5/16-18
33 784-5581A Shave Plate
34 710-0260 Carriage Bolt 5/16-18 x .62
35 684-0065 Impeller Assembly
36 715-0114 Pin
37 618-0121 26” Gear Assembly
38 605-5192A Spiral 26” RH
39 736-0188 Flat Washer
40 741-0493A Flange Bushing
41 605-5193A Spiral 26” LH
42 710-0890A Shear Bolt 5/16-18 x 1.5
43 712-0429 Lock Nut 5/16-18
44 741-0245 Hex Flange Bearing
45 784-5618 Bearing Housing
