Yard-Man 107 - Page 15

15
Model 107
Ref. No. Part No. Description
1.
647-0004 Control Handle Assembly
2.
710-1270 Oval C-Sunk Screw
3.
712-0324 Hex Lock Nut
4.
746-0883 Control Housing
5.
720-0295 Foam Grip
6.
749-0705A Upper Handle
7.
710-1205 Rope Guide
8.
710-1174 Carriage Bolt
9.
749-0928 Lower Handle
10.
720-0279 Wing Nut
11.
720-0284 Hand Knob
12.
714-0104 Hairpin Clip
13.
746-0554 Control Cable 40.5”
15.
726-0240 Cable Tie
16.
17098 Hinge Clip
17.
731-0872A Trail Shield
18.
682-0139 Cutting Deck Assembly: 20”
19.
736-0105 Bell Washer
20.
720-0426 Knob: Height Adjustment
21.
732-0404 Lever: Spring
22.
734-2004A Wheel Assembly
23.
736-0504 Wave Washer
24.
738-0102 Axle Bolt
25.
731-1426 Hubcap: Radial Spoke, Yellow
26.
738-0507B Shoulder Bolt
27.
15262B Pivot Bar
28.
682-3024 Handle Bracket Assembly RH
682-3025 Handle Bracket Assembly LH*
29.
738-0585 Stake Bolt
30.
732-0731 Torsion Spring
31.
14578 Height Adjust. Assembly RH
14579 Height Adjust. Assembly LH*
32.
782-7006 Mounting Bracket
33.
736-0270 Bell Washer
34.
710-0599 Hex Washer Hd. TT Screw
35.
710-0654A TT Sems Screw
36.
731-1409 Chute Deflector
37.
682-7002 Mulching Plug Assembly
38.
712-0431 Hex Lock Nut
39.
15261A Height Adjustment Plate
40.
731-1933 Cover: Front End
41.
748-0376C Blade Adapter
753-0588 Blade Adapter Kit (for service)
42.
742-0740 20” Mulching Blade
43.
736-0524A Blade Bell Support
44.
710-1044 Hex Bolt
45.
747-0710 Hinge Pin
46.
736-0451 Saddle Washer
Ref. No. Part No. Description
* Not shown in Illustration on previous page
NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Yard-Man
Green, the part number to order would be
700-xxxx-0665.
Yard-Man Green: 0665
Yard-Man Yellow: 0674
Powder Black: 0637
