Step 23: Door Assembly
Part 5
I: Above the Sliding Barrel Bolt, at desired location, place
Door Handle on (1175) Door Panel then attach using four
#7 x 3/4” Wood Screws, (F23.12, F23.13 and F23.14)
Hardware
4 x #7 x 3/4” Wood Screw
Sliding
Barrel Bolt
F23.12
F23.14
(1175)
Door
Panel
F23.13
(1175) Door
Panel
Door
Handle
#7 x 3/4”
Wood Screw
Components
1 x Door Handle
Sliding
Barrel Bolt
Door
Handle
#7 x 3/4”
Wood Screw
