(1175) Door
Panel
F25.4
Hardware
2 x #10 x 1-1/4” Black Pan Screw
D: Close the door and place Top
Tube Bracket on (
1175) Door Panel so it measures 9” (22.9 cm) from the end
of the panel. Attach with two #10 x 1-1/4” Black Pan Screws. Make sure tube is level
.
(F25.4 and F25.5)
Step 25: Attach Door Closer
Part 3
#10 x 1-1/4” Black
Pan Screw
(1175) Door
Panel
Top Tube
Bracket
Top Tube
Bracket
F25.5
Note: Door must be
closed for this step
9”
22.9 cm
To Next Page
