Yardline BRAXTON - Page 28

26
WINDOW PANEL

2" (5,1 cm)
PARTS REQUIRED:

Block

GAUGE BLOCK
GAA
Primed side UP
12" (30,5 cm)
6" (15,2 cm)
1-1/2" (3,8 cm)

3/8 x 48 x 84" (1 x 121,9 x 213,4 cm )
Place  window panel ush to the installed panel. Measure and locate the panel 1-1/2" above the top plate.  to check the 3/4" side measurement on the wall stud.
Secure the panel using 2" nails 6" apart on edges and 12" apart inside panel.

1
BEGIN
DOOR
48"
(121,9 cm)
