Two Nails
Two Nails
Panel
Panel 1/2"
(1,3 cm)
Rafter
52
ROOF PANELS
PARTS REQUIRED:
2" (5,1 cm)
3/4"
GAUGE BLOCK
GAA
3/4"
(1,9 cm)
Block
Place 2nd panel ush to the rafter marks. Panel should be a 1/2" from the outside edge of the
end rafter .
Secure panel using (2) 2" nails in the corners as shown. Panel will overhang 6-1/2" .
4
5
Place 2nd roof panel ush to the rafter marks and ush to the installed panel.
Use the 3/4" gauge block GAA to center panel over the rafter .
Secure panel using (2) 2" nails in the corners. Panel will overhang 6-1/2" .
39-3/4" x 96"
(101,0 x 243,8 cm)
48" x 39-3/4"
(121,9 x 101,0 cm)
To Next Page
